CopyBox 23 Micro SD Duplicator - direct copying microsd memory cards duplicator micro sd sdhc flash media
Introduction - Features - Specifications

Introduction - direct copying microsd memory cards duplicator micro sd sdhc flash media
The CopyBox 23 MicroSD duplicator is suitable for users who regularly need to duplicate Micro Secure Digital flash memory cards. The system operates completely stand-alone, without software or PC connection. The CopyBox 23 MicroSD can simultaneously duplicate 23 MicroSD cards (Micro SD and Micro SDHC) from one "master" card. Just insert the master MicroSD memory card into the master data port, insert empty Micro SD cards in the target data ports and press the button to start duplicating!

The CopyBox 23 MicroSD offers a maximum duplication speed of 33 MB/s, per individual port. This allows a data throughput of 118 GB per hour, per port. However, most current MicroSD cards offer lower writing speeds which makes the CopyBox production capacity dependant on the specific Micro Secure Digital media used.

Operating the CopyBox 23 MicroSD is quite simple; all functions are selected using the LCD display and control buttons on the front of the unit. This makes the CopyBox suitable for all users. In addition to the regular Copy and Compare functions, the CopyBox MicroSD duplicator also offers a number of special features;

- Capacity Check (checks the real flash memory capacity on a MicroSD memory card)
- Quick Format (formats MicroSD cards FAT16/32)
- Quick/Full Erase (erases data from MicroSD memory cards)
- DoD Erase (erases media 3x according to the Department of Defense standard)
- Measure Speed (measures the real read and write speeds of MicroSD cards)
- Media Check (checks if the entire MicroSD card can be read and written)

Features - direct copying microsd memory cards duplicator micro sd sdhc flash media
- Stand-alone operation, easy to follow menu.
- Suitable for all users, no computer knowledge required.
- One master data port and 23 target data ports.
- Maximum copy speed 33 MB/s, per port.
- Compatible with MicroSD and MicroSDHC flash memory cards.
- Format, Erase, Media Check en Capacity Check functions.
- Easy operation through a LCD display and control buttons.
- 100% reliable copies due to the integrated control functions.
- Also available as 7, 15, 31, 39 or 47 MicroSD port models.
- Also available as Secure Digital, Compact Flash or USB duplicator.

Specifications - direct copying microsd memory cards duplicator micro sd sdhc flash media
Included - direct copying microsd memory cards duplicator micro sd sdhc flash media Included - CopyBox 23 MicroSD
- Power Cable
- User Manual
Writing Speeds - direct copying microsd memory cards duplicator micro sd sdhc flash media Writing Speeds Maximum 33 MB/s per port (depending on the media used)
Connection - direct copying microsd memory cards duplicator micro sd sdhc flash media Connection Stand-alone
Dimensions - direct copying microsd memory cards duplicator micro sd sdhc flash media Dimensions (LxWxH) 42x18x28 cm
Weight - direct copying microsd memory cards duplicator micro sd sdhc flash media Weight 6,8 kg
Power Supply - direct copying microsd memory cards duplicator micro sd sdhc flash media Power Supply 100-120 VAC or 220-240 VAC, 50/60Hz, 250 Watt, Switchable
Operating Conditions - direct copying microsd memory cards duplicator micro sd sdhc flash media Operating Conditions - In use : 5C to 35C
(RH: 23% to 80% non condensing)
- Not in use : -20C to 60C
(RH: 23% tot 90% non condensing)
Data Ports - direct copying microsd memory cards duplicator micro sd sdhc flash media Data Ports 1x Read, 23x Write
Production Capacity - direct copying microsd memory cards duplicator micro sd sdhc flash media Production Capacity Maximum 118 GB per port, per hour
Supported Formats - direct copying microsd memory cards duplicator micro sd sdhc flash media Supported Formats FAT16/32/NTFS/Linux (Ext2,Ext3)
Supported Media - direct copying microsd memory cards duplicator micro sd sdhc flash media Supported Media  - MicroSD en MicroSDHC flash memory cards
Warranty - direct copying microsd memory cards duplicator micro sd sdhc flash media Warranty Standard 1 year carry-in warranty
